2 Description
2.1 Requirements for the Place of Installation
Please observe your national guidelines and specifications.
2.2 Technical Data
Measuring range
above hotspot
0…800 mm / 10 m (0…8 %)
above pitch angle
0…300 mm / 10 m (0…3 %)
below
0…700 mm / 10 m (0…7 %)
left
0…1000 mm / 10 m (0…10 %)
right
0…1000 mm / 10 m (0…10 %)
Light intensity
0…125 000 cd
Illuminance
0…200 lx
Measuring distance
100…500 mm
Adjustment path of lens centre above floor
240…1500 mm
Deviation of intensity
±5 %
Deviation from one axle
±5'
Compensation of ground unevenness
±3 %
Temperature
+5…+40 °C
Relative humidity
20…80 %
Supply voltage
100…240 V AC, 50/60 Hz
Charging voltage / Battery voltage
24 V DC / 12 V DC
Dimensions (W x H x D)
655 x 1770 x 720 mm
Net weight / Shipping weight
65 kg / 80 kg
Prototype release number
TPN100110935
