BA380701-en
2.4 Electronic Levelling
This headlight tester comes standard with an electronic position sensor which
determines the inclination angle of the device. The software compensates possible
deviations in the X- and Z-axes while calculating the position of the headlights.
The headlight tester may be set up on uneven surfaces even if the ground unevenness
is outside the permissible tolerances, provided that the maximum unevenness does
not exceed the headlight tester’s self-levelling capacity of 3%.
After enabling the respective function, the compensation values can be checked using
a dot or cross hair laser. See section “Operation > Settings > Calibrating the Camera
according to Directive”.
This function must be enabled exclusively by authorised service technicians and is ap-
plicable for the respective test surface only.
2.4.1 Compensation Coordinate Axes of MLT 3000
