Mahindra YUVRAJ 215 User Manual

11
Ring Gap
Top (mm) 0.25 to 0.45
Middle (mm) 0.60 to 0.85
Bottom (mm) 0.35 to 0.55
Piston
Type Re-entrant
Material Aluminium
Dia at crown 99.35 +/-0.015
Dia at skirt 99.88
Bumping Clearance 1.12 to 1.2
Number of Ring Groove (No.) 3
Ring Groove Width (mm)
Top Groove (mm) 2.7
Middle Groove (mm) 2
Bottom Groove (mm) 3
Ring Groove Clearance
Top groove (mm) 0.137
Middle groove (mm) 0.08/0.04
Bottom groove (mm) 0.09/0.07
Piston Pin
Inner Diameter (mm) 16
Outer Diameter (mm) 30
Clearance in piston (mm) 0.016/0.004
Clearance in con rod (mm) 0.434/0.268
Length (mm) 78
Cylinder Sleeve
Type Non Replaceable wet liner
Material Synthetic Low alloy gray cast iron
Wall thickness (mm) 8.5
Sleeve I.D. (mm) 100
Max. taper (mm) 0.015
Max. ovality (mm) 0.01
Sleave I.D. Discard limit (mm) 100.030 + 0.150
Engine Specifications

Mahindra YUVRAJ 215 Specifications

General

Engine Power	15 HP
Transmission	Sliding mesh
Number of Gears	6 Forward + 3 Reverse
Brakes	Oil immersed brakes
PTO Power	12 HP
Hydraulic Lifting Capacity	500 kg
Number of Cylinders	1
Rated Engine Speed	2300 RPM
Wheel Base	1490 mm
Weight	780 kg
Engine Type	Single Cylinder, Water Cooled
Fuel Tank Capacity	19 Litres
Steering	Mechanical
