Mahindra YUVRAJ 215 User Manual

29
83 Remove the 6 nos bolts of the flywheel
housing & remove the flywheel housing.
84 Remove the 4 nos bolts of the rear retainer
(17mm).
85 Use the two bolts as a puller & remove the
retainer.
86 Remove the crankshaft
87 Remove the thrust washer.
Flywheel
Housing
Crankshaft
Main Bearing
Retainer
Puller
Bolts
Puller
Bolts
Crankshaft
Thrust
Washer
Engine
Before Assembly ensure that
1 Use new gaskets, ‘o’ rings, Oil Seals and
fasteners.
2 All bearings must be cleaned & lubricated.
3 All moving parts must be smeared with
lubricants.
4 Smear oil on oil seal lip before fitment.
5 Use recommended Special Service tools.
Assembly :
Assembly is reverse of dismantling sequence.
Some of the important adjustments that needs
to be done are as follows :

Mahindra YUVRAJ 215 Specifications

General

Engine Power	15 HP
Transmission	Sliding mesh
Number of Gears	6 Forward + 3 Reverse
Brakes	Oil immersed brakes
PTO Power	12 HP
Hydraulic Lifting Capacity	500 kg
Number of Cylinders	1
Rated Engine Speed	2300 RPM
Wheel Base	1490 mm
Weight	780 kg
Engine Type	Single Cylinder, Water Cooled
Fuel Tank Capacity	19 Litres
Steering	Mechanical
