Mahindra YUVRAJ 215 User Manual

36
Transmission Torque Charts
Sr No Description Torque (Nm)
1 Transcase Cover to Transcase 21 - 25
2 Retainer Layshaft to Transcase 21 - 25
3 Retainer Splineshaft to Transcase 21 - 25
4 Retainer Rear Axle to RAC 21 - 25
5 PTO Housing to Transcase 21 - 25
6 Bull Cageto Transcase 41 - 50
7 RAC to Transcase 41 - 50
8 Clutch Hsg to Transcase 41 - 50
9 Cross Shaft to Ring Gear 41 - 50
10 Brake Hsg. To Bull Cage 41- 50
11 Clamping Plate to Transcase 21 - 25
12 Clutch ReleaseFork to Clutch Shaft 21 - 25
13 Washer Angular Contact Brg to Transcase 21 - 25
14 Nut For Bracket Spring Holding 21 - 25
15 Nut For Differential Stud 75 - 87
16 Bolt for Rail 41 - 50
17 Bolt for Reverse Idler Shaft 41 - 50
18 Lock Nut Bull Gear 110 - 120
19 Plug Magnetic Drain 68 - 75
20 Dipstick 47 - 54
21 Grease Nipple Clutch Release Sleeve 21 - 25
22 Grease Nipple Clutch Release Shaft 21 - 25
23 VTU to Transcase 64 - 75
24 VTU to Transcase 65 - 75
25 VTU to Transcase 41 - 50
26 VTU to Transcase 65 - 75

Mahindra YUVRAJ 215 Specifications

General

Engine Power	15 HP
Transmission	Sliding mesh
Number of Gears	6 Forward + 3 Reverse
Brakes	Oil immersed brakes
PTO Power	12 HP
Hydraulic Lifting Capacity	500 kg
Number of Cylinders	1
Rated Engine Speed	2300 RPM
Wheel Base	1490 mm
Weight	780 kg
Engine Type	Single Cylinder, Water Cooled
Fuel Tank Capacity	19 Litres
Steering	Mechanical
