Mahindra YUVRAJ 215 User Manual

5
General Specifications
Engine
Type FMW100 Water Cooled Direct Injection
NA type Engine
No. of Cylinders 1
Bore / Stroke mm 100 / 110
Displacement cc 863.5
Rated Governed Speed 2300 ± 50
Low Idle R.P.M. 1050 ± 100
High Idle R.P.M. 2550 ± 50
Valve Clearance Cold - Inlet - 0.1, Exhaust- 0.1, Hot - Inlet - 0.1,
Exhaust - 0.1
Air Cleaner Wire Mesh & Foam type Oil Bath
Nozzle Opening Pressure 247 to 261 kg/sqcm (250 + 8 bar)
Cooling System Water cooled pressurised, Cap Operating
Pressure 0.9 kg/sqcm, without thermostat
Clutch
Clutch Type 200 mm dry Single plate Crerametalic type
Transmission
Type Sliding Mesh
No of Gears 6 Forward & 3 Reverse with Hi-low-Reverse
Selector Lever
Power Take Off Rear mounted six splines, constant running - 450
R.P.M
Standard PTO rpm at rated engine speed 605
Brakes Totally enclosed self energising dry disc with
heavy duty friction linings
Hydraulic
Type Hytech Hydraulics. Fully live Hydraulic with
Position & Draft Controls
Lifting Capacity (Kgs) 450
Tractor
Steering Type Worm & Roller
Tyre Size Front 5.2 x 14 - 8pr

Mahindra YUVRAJ 215 Specifications

General

Engine Power	15 HP
Transmission	Sliding mesh
Number of Gears	6 Forward + 3 Reverse
Brakes	Oil immersed brakes
PTO Power	12 HP
Hydraulic Lifting Capacity	500 kg
Number of Cylinders	1
Rated Engine Speed	2300 RPM
Wheel Base	1490 mm
Weight	780 kg
Engine Type	Single Cylinder, Water Cooled
Fuel Tank Capacity	19 Litres
Steering	Mechanical
