72
Clean the area around the filler/level plug
before removing the plug. Add oil of
specified grade up to the slotted mark given
on dipstick whenever required.
b. Replacement of suction filter
Replace the suction filter after every 250
hrs. as per procedure mentioned below.
1) Put a clean tray below suction line filter.
2) Unscrew the filter cartridge and collect the
oil in the tray.
3) Apply oil on ‘O’ ring of the new filter.
4) Assembled it with hand as per give
instruction on the filter.
5) Add oil if necessary.
6) Remove air as per instruction given below.
c. Changing the oil
After every 1000 hrs. of operation system
should be drained, strainer cleaned, oil
refilled as follows.
1) Clean the area around the filter plug,
suction strainer & orific filter.
2) Remove drain plug then allow the oil to
drain in to a suitable container, remove the
orifice filter, clean or change.
3) Grip the suction strainer stub pipe near the
base & pull it out.
4) Clean the strainer in clean diesel fuel, using
a soft brush, then blow dry with
compressed air and replace with new if
necessary.
5) Install the drain plug on transmission
housing then fill the reservoir upto the
slotted mark of dipstick.
6) Run the engine for approximately for one
min. this will expel the air from the system
& allow the reservoir to be filled to
capacity.
7) If additional cylinders are used then add
extra oil with respected to cylinder capacity.
8) Install the fill plug cum dipstick.
Hy-tec Hydraulic
