Mahindra YUVRAJ 215 User Manual

77
Front Axle & Support
Torque Values
Sr No Description Torque (Nm)
1 Front Wheel Nut 65 to 75
2 Rear Wheel Nut 180 to 200
3 Drag link & Tie Rod Nut 35 to 40
4 Steering Arm Nut 110 to 120
5 Front Axle Support Mounting Bolts 110
6 Pivot Pin Mounting Bolt 21
7 Enine Mounting Bolts to Clutch Housing 45
(Shorter Length)
8 Enine Mounting Bolts to Clutch Housing 60
(Longer Length)
9 Rear Wheel Mounting Bolts 250
10 Front Wheel Mounting Bolts 110
11 Hood Bracket Mounting Bolts 60
12 PTO Cap Mounting Bolts 21
13 Hand Brake Mounting Bolts 21
14 Radiator Mounting Bolts 21
15 Hydraulic Filter Mounting Bolts 60
16 Seat Mounting Bolts 60
17 Steering Gear Box Mounting Bolt 60
18 Check Chain Mounting Bolts 105
Wear Limits
Sr No Description Initial Value Discard Value
(mm) (mm)
1 Front Axle Pivot Pin Bush I.D. 22.06 22.01
2 Pivot Pin To Bush Clearance 0.11 0.01
3 Front Axle Pivot Pin OD 22 21.95
4 Steering Knuckle Pivot shaft OD 25 24.95
5 Steering Knuckle Bush ID 25.06 25.01
6 Steering Knuckle To bush Clearance 0.11 0.01

Mahindra YUVRAJ 215 Specifications

General

Engine Power	15 HP
Transmission	Sliding mesh
Number of Gears	6 Forward + 3 Reverse
Brakes	Oil immersed brakes
PTO Power	12 HP
Hydraulic Lifting Capacity	500 kg
Number of Cylinders	1
Rated Engine Speed	2300 RPM
Wheel Base	1490 mm
Weight	780 kg
Engine Type	Single Cylinder, Water Cooled
Fuel Tank Capacity	19 Litres
Steering	Mechanical
