Mahindra YUVRAJ 215 User Manual

54
Sr. No Description
1. Pump Inlet
2. Spacer Compensator
3. Sleeve Compensator
4. Spool Compensator
5. Spring Compensator
6. Retainer Plug
7. Orifice
8. Spring Regulator Valve
9. Ball Regulator Valve
10. Regulator Piston
11. Valve Plug
12. Relief Valve
13. Ball Rider Relief Valve
14. Spring Relief Valve
15. Housing Relief Valve
16. Spool Control Valve
17. Sleeve Control Valve
18. Pilot Port Sleeve CV
19. Lifting Port Sleeve CV
20. Lowering Port Sleeve CV
Sr. No Description
21. Tank Port
22. Main Plug
23. Tank Port Bypass
24. Orifice (0.8 mm dia)
25. Seat Check Valve
26 .Ball Check Valve
27. Spring Check Valve
28. Sleeve Check Valve II. Valve Plug
29. Rider Check Valve
30. Retainer Check Valve
31. Spring Check Valve Retainer
32. Auxiliary Port
33. Isolator Valve
34. Lift Cylinder
35. Tank Port Regulator Valve
36. Tank Port Lowering
37. Piolet Line
38. Spring Main Valve
39. Relief Valve Reservoir Port
Hy-tec Hydraulics

Mahindra YUVRAJ 215 Specifications

General

Engine Power	15 HP
Transmission	Sliding mesh
Number of Gears	6 Forward + 3 Reverse
Brakes	Oil immersed brakes
PTO Power	12 HP
Hydraulic Lifting Capacity	500 kg
Number of Cylinders	1
Rated Engine Speed	2300 RPM
Wheel Base	1490 mm
Weight	780 kg
Engine Type	Single Cylinder, Water Cooled
Fuel Tank Capacity	19 Litres
Steering	Mechanical
