Mahindra YUVRAJ 215 User Manual

64
f. Raise the pressure to 125-140 kg/cm
2
. Do
not raise the pressure sufficiently to blow
the relief valve. Wait for 2-3 minutes and
observe plugs and ports for leakage. If any
of these plugs are leaky tighten it or replace
if required.
g. IF oil is coming out from coupling pressure
pipe, or port (9-3) ‘check valve’ is leaky,
remove check valve and observe sear for
any damage, observe ‘O’ ring for any cut
and deformation etc. Before reassembling,
change ‘O’ ring on seat.
h. After reassembling, observe the pressure
guage, if the pressure is coming down, and
if oil is leaking from clearance between
main spool and sleeve is more than (0.010-
0.012) mm. Replace the spool with the
spool of bigger diameter and do necessary
lapping.
Hy-tec Hydraulics

Mahindra YUVRAJ 215 Specifications

General

Engine Power	15 HP
Transmission	Sliding mesh
Number of Gears	6 Forward + 3 Reverse
Brakes	Oil immersed brakes
PTO Power	12 HP
Hydraulic Lifting Capacity	500 kg
Number of Cylinders	1
Rated Engine Speed	2300 RPM
Wheel Base	1490 mm
Weight	780 kg
Engine Type	Single Cylinder, Water Cooled
Fuel Tank Capacity	19 Litres
Steering	Mechanical
