Mahindra YUVRAJ 215 - Page 67

67
2 Remove the clevis pin.
3 Remove the DC inner rocker assembly.
4 Remove Bush DC Feedback shaft.
5 Remove bolt from cam of cable DC
feedback.
6 Remove DC rocker Allen Screw.
7 Remove DC rocker assembly.
DC Outer
Link
Spacer
Oil
Seal
Bush
DC Inner
Rocker
Bush
Bolt DC
Feedback
Cable
Hy-tec Hydraulic
DC Inner
Rocker
Clevis Pin
DC Rocker
Assembly
Clevis
Pin
