Mahindra YUVRAJ 215 User Manual

74
Noisy System
TROUBLE PROBABLE CAUSE REMEDY
TROUBLE SHOOTING
Regulator valve not opening
(oil flows through relief
valve when lift arms are
fully raised
Links creep up when
working with external
cylinder
 Low oil level
 Clogged suction strainer
 Air in the system
 Load movement restricted
 Restriction in high pressure
line
 Pipes vibrating
 Faulty pump
 Position of position control
stop lever not correct
 Orifice filter choked
 Regulator piston stuck in
closed position
 Isolator valve not fully closed
 Isolator valve is leaking
Fill to correct level
Remove and clean
Check oil level and suction
line joints
Check for free movement of
the links and that load is not
fouling tractor
Remove and clean
Check the unions and
tighten.
Repair or replace
Adjust
Clean
Remove and correct
Close
Rectify / replace
Hy-tec Hydraulic

Mahindra YUVRAJ 215 Specifications

General

Engine Power	15 HP
Transmission	Sliding mesh
Number of Gears	6 Forward + 3 Reverse
Brakes	Oil immersed brakes
PTO Power	12 HP
Hydraulic Lifting Capacity	500 kg
Number of Cylinders	1
Rated Engine Speed	2300 RPM
Wheel Base	1490 mm
Weight	780 kg
Engine Type	Single Cylinder, Water Cooled
Fuel Tank Capacity	19 Litres
Steering	Mechanical
