Mahindra YUVRAJ 215 User Manual

83
10 Remove the four bolts on the end cover &
remove the end cover. (Adjusting screw
need to rotate to take cover off.)
11 Adjusting screw need to rotate to take cover
off.
12 Remove the circlip.
13 Remove the adjuster screw with plain
washer.
14 Remove the worm assembly.
15 Remove the main steering column
Steering
Gear Cover
Cover
Adjusting
Screw
Circlip
Mounitng
Bolt
Adjuster
Screw
Worm
Assembly
Main
Steering
Column
Steering Assembly

Mahindra YUVRAJ 215 Specifications

General

Engine Power	15 HP
Transmission	Sliding mesh
Number of Gears	6 Forward + 3 Reverse
Brakes	Oil immersed brakes
PTO Power	12 HP
Hydraulic Lifting Capacity	500 kg
Number of Cylinders	1
Rated Engine Speed	2300 RPM
Wheel Base	1490 mm
Weight	780 kg
Engine Type	Single Cylinder, Water Cooled
Fuel Tank Capacity	19 Litres
Steering	Mechanical
