Man D 2840 LE 301

Ø
Ø
Limit values
Service Data
Dimensions
165
Oil pump
Oil pump wheel Gear width 43 mm
Shaft: 21,930−21,940 mm
Bore Ø in housing: 22,000−22,017 mm
Radial clearance 0,040−0,106 mm
Press on force: 12200 N
Housing depth: 43,000−43,039 mm
Axial clearance: 0,050−0,128 mm
42,950−42,911 mm
11,5−11,7 mm
Drive wheel with oil pump wheel
11,5−11,7 mm
Shaft: 21,930−21,940 mm
Bore in drive gear: 21,870−21,885
mm
Press on force: 12000 N
Backlash:
Drive wheel and crankshaft wheel:
0,099−0,451 mm
