Replacing crankshaft seal
(flywheel end)
79
Removing shaft sealing ring
Fig. 1
Remove flywheel, see page 77.
Prise out the seal using the special tool (Fig. 2) or
a screwdriver.
Fig. 2
Special tool for levering out the crankshaft seal.
Fit shaft sealing ring
Fig. 3
When fitting a new shaft sealing ring, you must
also replace the flywheel bearing race.
Insert the new shaft sealing ring into the flywheel
housing.
Use mandrel (special tool) to drive in sealing ring
until flush.
Refer to the comments and assembly instructions
on page 81.
