Engine lubrication schedule
20
1 2 3
4
5
67789
5
À Oil line to crankshaft
Á High−pressure pump lubrication
 Lubricating oil lines to exhaust turbochargers
à Oil return line from exhaust turbochargers
Ä Holes for main bearing lubrication
Å Oil pump with oil pressure relief valves
Æ Holes for conrod bearing lubrication
Ç Oil drain screw
È Oil intake pipe
