5
Oil injection nozzle
72
Fig. 5
The oil spray from each nozzle must reach the
entry bore hole of the cooling duct in the piston
crown À and cams Á without hindrance.
Bent oil injection nozzles must on no account be
repaired.
Turn the engine. The crankshaft drive or pistons
must not collide with the oil injection nozzle.
Fitting the oil pan, see page 69
Top up engine oil.
1
2
1
1
2
2
1
