Pilot clutch
128
Wear limits for the friction disk and friction ring above which
it is advisable to replace these components
Type
005 010 020 030 035 040 045 050 055 060 065 070 075 080 085 090
Thickness 3 3 3 4 4 4 4 5 5 6 6 6 7 7 8 8
Permissi-
ble wear
0,3 0,3 0,3 0,4 0,4 0,4 0,4 0,5 0,5 0,6 0,6 0,6 0,7 0,7 0,8 0,8
Caution:
All front-mounted clutches are balanced with a balance quality of Q = 6.3!
If running after repairs is not smooth the clutch must be rebalanced with the limits contained in
the assembly drawing.
Balancing
All front-mounted clutchs are balanced with a balance quality of Q = 6.3! In the production of new parts in
our company the parts are well below the permissible limits. The wearing parts to be replaced in the event
of a repair are rotationally symmetric and experience has proven that they do not lead to an impermissible
or disturbing imbalance.
If contrary to expectation running is irregular the balancing must be checked. The assembly drawing is to
be referred to for the permissible imbalance data.
