- 9 -
Removal: unlock quick release plate safety lock ① , remove the quick release plate while
pressing anti-drop column ② .
2
1
Vertical Installation
Unlock quick release plate safety lock ① located on the vertical mounting plate, push
the plate with the camera mounted into slot ② , lock safety lock ③ once the camera is
approximately balanced.
1
2
3
Removal: unlock quick release plate safety lock ① located on the vertical mounting plate,
remove the quick release plate while pressing anti-drop column ② .
1
2
