Manitou 150 AETJ - Page 30

1 - WHITE ARROW Part No.498327
Indicates forward driving direction, e OPERATING THE PLATFORM: TRANSPORT/
WORKING POSITION.
2 - BLACK ARROW Part No.498326
Indicates reverse driving direction, eOPERATING THE PLATFORM: TRANSPORT/WORKING
POSITION.
3 - WHEEL LOAD 150AETJ (150AETJC)-150AETJ3D (150AETJC3D) Part No.679342
4 - WHEEL LOAD
170AETJL Part No.516913
Indicates the maximum ground load per wheel.
NOTE: Each access platform has its own specific wheel load. Please refer to this sticker
to find out the value.
5 - EMERGENCY CONTROL PROCEDURE
Part No.52706358 / Part No. 679307
Illustrations:
#1
= first version,
#2
= second version.
Indicates the procedure to be followed for using
the emergency controls.
NOTE: eRESCUE PROCEDURE.
2 - 10
1
1
52706358-A
A4
B4
B6
A6
#2#1
647536 (26/11/2020) 150 AETJ/AETJ 3D - 150 AETJ C/AETJ C 3D - 170 AETJ L
