18 - LIFTING POINT Part No.833291
Indicates the location of the platform's lifting points, e3-MAINTENANCE: OCCASIONAL
OPERATION: LIFTING THE PLATFORM.
17 - HARNESS ATTACHMENT POINT Part No. 684503 (1) / 834438 (2)
Indicates the location of the safety harness attachment points, eSAFETY COMPONENTS:
HARNESS ATTACHMENT POINTS.
NOTE: (1) = 1st version. (2) = 2nd version. The reference (1) must be replaced by
reference (2) for spare parts orders.
20 - RESET BUTTON SPS - SECOND VERSION (OPTION) Part No.52676715
Indicates the location of the reset button SPS of the SECONDARY PROTECTION SYSTEM
option SPS - SECOND VERSION.
19 - RESET BUTTON SPS - FIRST VERSION (OPTION) Part No.52513971
Indicates the location of the reset button SPS of the SECONDARY PROTECTION SYSTEM
option SPS - FIRST VERSION "SafeManSystem".
2 - 15
(1)
(2)
647536 (26/11/2020) 150 AETJ/AETJ 3D - 150 AETJ C/AETJ C 3D - 170 AETJ L
