Manitou 150 AETJ - Page 46

DIMENSIONS AND DIAGRAM 170AETJL
WHEELS (600X190) WHEELS (27X10X12)
A mm 6,840 6,875
A1 mm 5,120 5,155
B mm 2,000
B1 mm 1,000
C mm 1,970 2,005
C1 mm 2,040 2,075
D mm 1,750 1,910
E mm 140 175
F mm 455 490
G mm 2,005 1,970
H mm 4,300 4,400
I mm 5,600 5,600
J mm 2,890 2,950
K ° 32.5 44.5
L mm 80 10
2 - 26
E
D
L
J
G
H
I
B
B1
C
C1
F
A
A1
K
647536 (26/11/2020) 150 AETJ/AETJ 3D - 150 AETJ C/AETJ C 3D - 170 AETJ L
