19
MARA PIGGYBACK SERVICE MANUAL
4
5
If the service warrants
replacement of bushings
within the air piston, use a
½-13 UNC bottoming tap and
the Manitou clamp block to
remove the bushings. (See
Manitou Air Piston Bushing
and Seal Tool instructions for
information)
SHaft service
Remove inner shaft O-ring.
