29
MARA PIGGYBACK SERVICE MANUAL
1
Clamp the shock damper tube
in the vise on the eyelet. Fill
the damper tube to the top
with 5wt damper uid. *For
cold weather use Maxima
Synthetic All Temperarture
3wt fork oil. (PN 141-34078-
K016)*
Install the main shaft and
piston into the shock damper
tube. Add oil if needed to top-
o the damper tube once the
piston is installed.
2
3
Remove the bleed screw on
the air piston so that air can
escape while the air piston is
threaded on to the damper
tube. Torque the air piston to
26Nm (230in-lb). Replace the
bleed screw.
bleed and fill
