6
MARA PIGGYBACK SERVICE MANUAL
SHOCK TEARDOWN
1
Unscrew air cap, thread on
shock pump to note pressure.
Using the pump’s pressure
release button release all air.
Depress Schrader valve with
a small tool to ensure all air is
released. Remove valve core.
Clamp upper eyelet of shock in
vise. If Trunnion shock, clamp
on trunion mounts. (Use soft
jaws to not damage the shock)
2
3
With the shock top cap in a
vise use the air can wrench PN
142-37512-K033 to loosen the
air can on the shock. DO NOT
completely remove the air can
at this point, only loosen one
full turn. Removing the air
can completely at this point
will damage the threads due
to pressure in the negative
chamber.
CAUTION
Do not proceed to the next
step without completely
depressurizing air spring.
To Next Page
