MARA PIGGYBACK SERVICE MANUAL
Torque spec
TORQUE SPECS
COMPRESSION ASSEMBLY NOMINAL TOLERANCE
PISTON INTO CARTRIDGE 50 in-lb ±3
NUT ONTO LSC SHAFT 35 in-lb ±3
CARTRIDGE INTO TOPCAP 50 in-lb ±5
LOCKOUT ASSEMBLY
BOLT IN LOCKOUT BODY 50 in-lb ±3
RESERVOIR
RESERVOIR INTO TOPCAP 80 in-lb ±10
SCHRADER INSERT INTO RESERVOIR 50 in-lb ±3
MAIN SHAFT
SHAFT INTO TOPCAP 100 in-lb ±10
NUT TO SHAFT 45 in-lb ±3
DAMPER BODY
DAMPER BODY TO AIR PISTON 230 in-lb ±10
BLEED SCREW INTO DAMPER BODY 12 in-lb ±2
TOP CAP
KNOB SCREWS 5 in-lb ±1
AIR CAN TO TOPCAP 95 in-lb ±5
SChRADER VALVE CORE 3 in-lb ±1
Table 1: Torque Spec
