30
MARA PIGGYBACK SERVICE MANUAL
4
Flip the shock and clamp the
eyelet (or clamp across the
trunnion faces) into the vise.
With the lockout assembly
removed, ll the compression
assembly with oil. Actuate the
lockout lever 5-10x to work air
out of the shock.
Place the lockout assembly
into its location in the top cap.
Be sure the face seals stay in
place.
5
6
While pushing down rmly to
engage the O-ring thread the
reservoir onto the top cap and
torque to 9Nm (80 in-lb). Fill
the reservoir 2/3 full of oil.
bleed and fill
