CHARACTERISTICS OF MASTS WITH ROLLERS AND LOAD CHARTS
NOTE: The specifications given are not binding on the manufacturer and can be modified without prior notification.
MI-X 50L D
MI 50L D
MI 50L G
MI-X 60 D
MI 60 D
MI 60 G
MI-X 70 D
MI 70 D
MI 70 G
LIFT
HEIGHT
FREE LIFT HEIGHT OF MAST TILTING
VALUES ON FORKS VALUES WITH TDL
Height
at max. capacity
(mm)
Capacity
at maximum height
COG at 500mm
(kg)
Height
at max. capacity
(mm)
Capacity
at maximum height
COG at 500mm
(kg)
mm
h2
h1
lowered
h4
extended
with
back-rest
h4
extended without back-rest
α
FRONT
β
REAR
5.0 t 6.0 t 7.0 t 5.0 t 6.0 t 7.0 t 5.0 t 6.0 t 7.0 t 5.0 t 6.0 t 7.0 t
5.0 t - 6.0 t
7.0 t
5.0 t - 6.0 t
7.0 t
DUPLEX
TOTAL
VISIBILITY
3000 160 2500 4407 3995 4167 6° 12° 3000 3000 3000 5000 6000 7000 3000 3000 3000 4500 5500 6500
3300 160 2650 4707 4295 4467 6° 12° 3300 3300 3300 5000 6000 7000 3300 3300 3300 4500 5500 6500
3600 160 2800 5007 4595 4767 6° 12° 3600 3600 3600 5000 6000 7000 3600 3600 3600 4500 5500 6500
4000 160 3000 5407 4995 5167 6° 12° 4000 4000 4000 5000 6000 7000 4000 4000 4000 4500 5500 6500
4500 160 3300 5907 5500 5667 6° 6° 4500 4500 4500 5000 6000 7000 4500 4500 4500 4500 5500 6500
5000 160 3550 6407 6000 6167 6° 6° 5000 5000 5000 5000 6000 7000 5000 5000 5000 4500 5500 6500
DUPLEX
FREE LIFT
3000 1495 1335 2450 4137 3955 4115 6° 12° 3000 3000 3000 5000 6000 7000 3000 3000 3000 4500 5500 6500
3300 1645 1485 2600 4437 4255 4415 6° 12° 3300 3300 3300 5000 6000 7000 3300 3300 3300 4500 5500 6500
3600 1795 1635 2750 4737 4555 4715 6° 12° 3600 3600 3600 5000 6000 7000 3600 3600 3600 4500 5500 6500
4000 1995 1835 2950 5137 4955 5115 6° 12° 4000 4000 4000 5000 6000 7000 4000 4000 4000 4500 5500 6500
TRIPLEX
FREE LIFT
4500 1500 2725 5907 5735 6° 6° 4500 4500 4500 4500 5500 6400 4500 4500 4500 4000 5000 5900
4800 1600 2825 6207 6035 6° 6° 4800 4800 4800 4500 5500 6300 4800 4800 4800 4000 5000 5800
5000 1672 2875 6407 6213 6° 6° 5000 5000 5000 4500 5500 6300 5000 5000 5000 4000 5000 5800
5500 1800 3075 6907 6785 3° 6° 5500 5500 5500 4200 5200 6100 5500 5500 5500 3700 4700 5600
6000 2000 3225 7407 7235 3° 6° 6000 6000 6000 4000 5000 5500 6000 6000 6000 3500 4500 5000
2-16
647650 (19/02/2018)
M
I-X 50L/60/70 D C ST3A S2 / MI 50L/60/70 D ST3B S2 / MI 50L/60/70 G S2
