Manitou MI-X 50L D C ST3A S2 - Ignition Switch; Seat Belt; Steering Wheel Tilting Knob

3 - STEERING WHEEL TILTING KNOB
- Push knob 1 forwards.
- Tilt the steering wheel to the desired position.
- Pull the knob back to lock the steering wheel in position.
2 - SEAT BELT

IMPORTANT

In no event should the lift truck be used if the seat belt is defective (fixing, locking, cuts, tears, etc.).
Repair or replace the seat belt immediately.
- Sit correctly on the seat.
- Check that seat belt is not twisted.
- Place the seat belt at hip level.
- Attach the seat belt and check that it locks.
- Adjust the seat belt to your body shape without compressing your pelvis and without excessive slack.
4 - IGNITION SWITCH
This switch has 3 positions:
• A - Ignition switched off and engine stopped.
• B - Ignition
( Only for MI .. G) .
- Ignition and engine preheat ( Only for MI-X .. D and MI .. D) .
• C - The engine starts, and returns to position B as soon as the key is released.
2-23
1
B
A
C
647650 (19/02/2018)
M
I-X 50L/60/70 D C ST3A S2 / MI 50L/60/70 D ST3B S2 / MI 50L/60/70 G S2
