R8 PRO SERVICE GUIDE
2
With a 5mm socket, unthread the open mode adjuster and
remove the black “VTT” adjustment knob.
Note: Be sure to hold the knob still while removing the
nut. The damper adjuster may be damaged if the knob
is over torqued.
VTT PRO - X REMOTE KNOB REMOVAL
Holding the outer surface of the cable stop, lift the entire
remote knob assembly out of the top-cap. The remote
knob may spin when it disengages from the adjuster;
this is normal. Further disassembly of the knob assembly
is not needed.
3
