18
R8 PRO SERVICE GUIDE
4
Attach M5x0.8 Luer lock fitting to a syringe
(141-30695-K020). Fill the syringe with 3wt Damper oil
(141-34078-K016).
5
6
IMPORTANT: The VTT adjuster should be set to “OPEN”
position during the bleed process. With the shaft fully
compressed, squeeze the bladder to expel any air
ingested into the damper. With the bladder compressed
attach the filled fyringe M5x.8 adapter to top-cap
bleed port.
R8 SEALED DAMPER SERVICE
Holding the damper end-cap up-right in vise
simultaneously compress the filled syringe SLOWLY to
fill the damper with fresh oil. Refill the syring as needed
until oil is drawn into the upper syringe.
