Manitou R8 PRO - Page 32

32
R8 PRO SERVICE GUIDE
R8 PRO EXPLODED VIEW & PARTS
ITEM # PART DESCRIPTION KIT NUMBER
1 CROWN-STEER ASSY, 440S, M3IX0.8, MY25 R8 141-41368-K001
2 CASTING, 29” MY25 R8 GLOSS BLACK 141-41368-K002
3 AXLE, HEXLOCK SLR, 110 (WITH HARDWARE) 141-33147-K008
4 AXLE HARDWARE, HEXLOCK SL2 141-33147-K006
5 IVA ASSY M31XO.8, 31.00 R8 141-32668-K014
6 DORADO AIR SPRING ASSY (INCLUDES TRAVEL SPACERS) 141-41368-K003
7A DAMPER CARTRIDGE, VTT-PRO, 34MM M32X1, 18MM REMOTE KNOB 141-341368-K004
7C DAMPER CARTRIDGE, VTT-PRO 34MM M32X1, MANUAL KNOB 141-41368-K009
8A KNOBS, VTT-PRO, REMOTE 18MM PULL 141-41368-K005
8B KNOBS, VTT-PRO, REMOTE 10MM/14MM PULL 141-41368-K006
8C KNOBS, VTT-PRO, MANUAL 3-POSITION 141-41368-K010
9 FOOT-NUT, M12X1.5 SHAFT (2PC) 141-39022-K017
10 SEALS, 34MM, SKF W/ FOAM RINGS 141-39022-K020
11 AIR PISTON, SEAL ONLY QUAD-RING (31.00 LEG) 141-32155-K012
12 TRAVEL ADJUST SPACER KIT 141-30159-K012
13 TSR SCREW, PPC 141-36713-K035
REF DECAL KIT, MY25 R8 141-41368-K008
REF REBUILD KIT, MY25 R8 141-41368-K007
REF BLADDER, CARTRIDGE, NBR MY25+ TBD
REF FENDER & HOSE-GUIDE KIT 141-36103-K001
REF FENDER KIT 14136103K002
REF HOSE GUIDE KIT 14136103K003
REF DEUCE LEVER + CABLE, 3P18MM, 22.2MM AM 19341336A201
REF ACE/DEUCE LEVER + CABLE, 3P18MM, 22.2MM AM 19341336A001
REF KIT, CABLE, DEUCE LEVER 36141484
