6-3
Published 10/19/2017, Control # 618-00
GRT880 SERVICE MANUAL SWING SYSTEM
9
2
4
1
6
7
5
8
FIGURE 6-1
6470-1
1
3
Picture may not be same model as your
machine, it is for reference only.
1 Breather Plug 6 Level Plug
2Filler Plug 7Motor
3 Swing Drive and Brake 8 Pinion
4 Hydraulic Apply Brake Port 9 Drain Plug
5 Hydraulic Release Brake Port
Reference Only
