8-31
GRT880 SERVICE MANUAL UNDERCARRIAGE
8
Published 10/19/2017, Control # 618-00
GROVE
8804-114
FIGURE 8-30
Item Description
1 Cylinder Clevis Pin (rod end)
2 Mid-extend Pin
3 Plates and Wear Pads (beam mounted)
4 Cylinder Clevis Pin (piston end)
5 Wear Pad Assembly (O/R box mounted)
2
1
3
5
4
