Published 4-22-15, Control # 556-00 2-69
RT530E-2 SERVICE MANUAL HYDRAULIC SYSTEM
2
GROVE
FIGURE 2-38
6722
11
10
7
6
5
4
3
8
9
2
1
Item Description
1 Barrel
2Rod
3 Head
4Piston
5Nut
6O-ring
Item Description
7 Piston Seal Ring
8O-ring
9 Back-up Ring
10 Rod Seal Ring
11 Wiper Ring
Reference Only
