Manitowoc Grove RT530E-2 Service And Maintenance Manual

Published 4-22-15, Control # 556-00 3-27
RT530E-2 SERVICE MANUAL ELECTRIC SYSTEM
GROVE
3
6291 Axle Lifting Front Right solenoid
6292 Axle Lifting Rear Left solenoid
6293 Axle Lifting Rear Right solenoid
6294 Pressure Axle Lifting Front Left solenoid
6295 Pressure Axle Lifting Front Right solenoid
6296 Pressure Axle Lifting Rear Left solenoid
6297 Pressure Axle Lifting Rear Right solenoid
6298 Drive out cylinder, Jib moves ahead from boom
6299 Retract cylinder, jib moves to boom
6400 Main Hoist Down solenoid
6401 Main Hoist Up solenoid
6402 Aux Hoist Down solenoid
6403 Aux Hoist Up solenoid
6404 Derricking Down solenoid
6405 Derricking Up solenoid
6406 Tele Cylinder Extend solenoid
6407 Tele Cylinder Retract solenoid
6408 Slewing Right solenoid
6409 Slewing Left solenoid
6410 Lower Brake Main Hoist solenoid
6411 Raise Lower Brake Main Hoist solenoid
6412 Lower Brake Aux Hoist solenoid
6413 Raise Lower Brake Aux Hoist solenoid
6414 Pilot Supply solenoid
6415 Slew Brake Release solenoid
6416 Enable high Speed Tele solenoid
6417 Lock Telecylinder Boom Section solenoid
6418 Charge Cylinder Tube solenoid
6419 Release Boom Down solenoid
6420 Hold Unlock Position solenoid
6421 Select Boom Section Telecylinder solenoid
6422 Jib Down solenoid
6423 Jib Up solenoid
6424 Cabin Down solenoid
6425 Cabin Up solenoid
6426 Turntable Lock solenoid
6427 Turntable Unlock solenoid
6428 Counterweight Lower solenoid
Fault Code Component Description
Reference Only
