Manitowoc Grove RT530E-2 Service And Maintenance Manual

Published 4-22-15, Control # 556-00 8-3
RT530E-2 SERVICE MANUAL UNDERCARRIAGE
GROVE
8
FIGURE 8-1
10
11
22
7
9
17
12
15
16
8
3
19
20
18
1
1
2
21
4
14
13
5
8481
6
23
Item Description
1 Cotter Pin
2Pin
3Pin
4 Lockout Cylinder
5 Steer Cylinder
6
7Pin Weld
8Pin Weld
9 Capscrew
10 Lockwasher
11 Flatwasher
Item Description
12 Capscrew
13 Washer
14 Hex Nut
15 Capscrew
16 Lockwasher
17 Flatwasher
18 Sensor Plate
19 Capscrew
20 Lockwasher
21 Rear Axle
22 Grease Fitting
23 Flatwasher
Reference Only
