HYDRAULIC SYSTEM RT770E
2-82
Published 11/26/2014, Control # 447-05
FIGURE 2-41
17
18
1
7
19
8
5
10
11
12
14
13
15
16
2
4
6
9
7347
20
3
Item Description
1 Barrel
2Rod
3 Head
4 Lug
5Piston
6Spacer
7Nut
8Bolt
9 Locknut
10 Holding Valve
Item Description
11 O-ring
12 Wear Ring
13 Piston Seal
14 O-ring
15 Backup Ring
16 Rod Seal
17 Wiper Ring
18 Bleeder Plug
19 Plug
20 O-ring
