InstallationandOperationManual 
8

NetworkCircuit

 ClassBcircuit
 Forupto110panelsand/orremoteannunciatorsconnection
 Communicationsprotocol:CAN
 Max.linecapacitance=0.05uF
 Max.lineresistance=25Ohm
AddressableLoop
Circuits

 MaximumCurrent(short):0.4A
 ClassA/ClassBcircuit
 252addresses:detectorsandmodulesmax
 Outputvoltagerange:20.2V~26.2V
 Maximumnormalstandbycurrent:100 mA
 Maximumalarmcurrent:220mA
 Max.linecapacitance=0.1uF
 Max.lineresistance=10Ohm

SystemComponents
ComponentsOverview
Table3 describestheFW106/FW106Ccomponents.
Table3SystemComponents
Model Description FW106/FW106CComponents
FW201/FW201C AMI(AdvancedMachineInterface)
√
FW391 PTU(Power‐supplyTransformerUnit)
√
FW397 PCU(Power‐supplyandChargerUnit)
√
FW327 ALU(AddressableLoopUnit)
√
FW337 NOU(NotificationOutputUnit)
√
FW347 ROU(RelayOutputUnit)
√
FW357 XNU(ExternalNetworkUnit)
√

 
