InstallationandOperationManual 
34

Ifthis XNUis locatedin themiddle ofthe externalnetwork circuit,thejumper
mustbeswitchedto“OFF”.

PleaserefertotheUnitAddressSettingsectiontosettheXNU’saddress

AuxiliaryPowerOutputWiring
The Power‐supply and Charging Unit provide auxiliary power output connection. This power output can be
configured as resettable or non‐resettable. The resettable terminal interrupts the power for6 seconds aftera
resetcondition.


Figure28AuxiliaryPowerOutputWiring

CommunicationPortConnection
AnEthernetstandardplugisprovidedfortemporaryconnectiontoacomputerforpanelprogramming.
TheEthernetstandardplugisconnectedtotheEthernetportofthecomputerthathastheFW401configurator
tool.Thisisusedtouploadand/ordownloadpanelconfigurationforprogramming.


AL AH BL BH
OFF
XNU
Jumper
