Marantz PM-10 Service Manual

BLOCK DIAGRAM
BAL1
CD
LINE1
LINE2
REC
PM-10S1 BLOCK DIAGRAM
PHONO
+
-
RIAA
I/V
RIAA
HEADPHONE
OUT
Rch
Rch
INPUT SELECTOR
Bi-AMP
PHONO EQUALIZER
SPEAKER
OUT
SPK A
SPK B
+
-
-
+
+
-
+
-
REC
OUT
REC OUT BUFFER
DETECT
LINE DETECT
AMP
I/V
VOL
+
-
LINEAR CONTROL VOLUME
MUTE
BAL2
I/V
VOL
+
-
+
-
+
-
MUTE
+
-
+
-
HP DETECT
CLASS D
OUTPUT STAGE
HP AMP
+
-
POWER
AMP
IN
HDAM-SA3
module
HDAM-SA3
(on board)
The circuit which is off
in Purest Mode On
NC500
NC500
Darlington
Push-Pull
Darlington
Push-Pull
29
Caution in
servicing
Electrical Mechanical Repair Information Updating

Marantz PM-10 Specifications

General

Type	Integrated Amplifier
Frequency Response	5 Hz - 50 kHz
Total Harmonic Distortion	0.005%
Dimensions	440 x 168 x 453 mm
Weight	21.5 kg
Damping Factor	500
Available Colors	Silver, Black
Power Output	200W per channel (8Ω)
Input Sensitivity	220 mV / 22 kohm
