Marantz PM-10 Service Manual

SPECIAL MODE
Special mode setting button
b
No. 1 : Turn on the power. When the ID appears in the display, press and hold button "
A
" for 5 seconds or longer.
No. Mode Button A Button B Descriptions
1 Service mode F.C.B.S. ID -
The rmware version, display check, communication test of BUS, protection detection count and serial number display appear in the display.
The memory is cleared and the unit is initialized.
(See 1. Service mode)
2 ERROR MESSAGES - -
Table of Error Message.
(See 2. ERROR MESSAGES)
3 Protection operation - -
Displayed when an error occurs.
(See 3. Protection operation)
F.C.B.S ID
X
50
Caution in
servicing
Electrical Mechanical Repair Information Updating

Marantz PM-10 Specifications

General

Type	Integrated Amplifier
Frequency Response	5 Hz - 50 kHz
Total Harmonic Distortion	0.005%
Dimensions	440 x 168 x 453 mm
Weight	21.5 kg
Damping Factor	500
Available Colors	Silver, Black
Power Output	200W per channel (8Ω)
Input Sensitivity	220 mV / 22 kohm
