Marantz PM-10 Service Manual

DISASSEMBLY
Flowchart
• Remove each part following the ow below.
• Reassemble the removed parts in the reverse order.
• Read "SAFETY PRECAUTIONS" before reassembling the removed parts.
• If wire bundles are removed or moved during adjustment or part replacement, reshape the wires after completing the work. Failure to shape the wires correctly may cause problems such as noise.
• See "EXPLODED VIEW"
TOP COVER
SIDE PANEL
POWER PCB
DISASSEMBLY
5. POWER PCB
and "EXPLODED VIEW"
POWER PCB
Ref. No. of EXPLODED VIEW : P 1-2
PHONO ASSY
DISASSEMBLY
6. PHONO ASSY
and "EXPLODED VIEW"
PHONO PCB
Ref. No. of EXPLODED VIEW : P 1-1
INDUCTOR PCB
DISASSEMBLY
7. PHONO ASSY
and "EXPLODED VIEW"
INDUCTOR PCB
Ref. No. of EXPLODED VIEW : P 1-10
AC PCB
DISASSEMBLY
8. AC PCB
and "EXPLODED VIEW"
AC PCB
Ref. No. of EXPLODED VIEW : P 3-2
POWER TRANS
DISASSEMBLY
9. POWER TRANS
and "EXPLODED VIEW"
POWER TRANS
Ref. No. of EXPLODED VIEW : L 001
AMP ASSY
DISASSEMBLY
10. AMP ASSY
and "EXPLODED VIEW"
NC500
Ref. No. of EXPLODED VIEW : MA001
NC500
Ref. No. of EXPLODED VIEW : MA002
NC500
Ref. No. of EXPLODED VIEW : MA003
NC500
Ref. No. of EXPLODED VIEW : MA004
CONNECT PCB
Ref. No. of EXPLODED VIEW : P 3-1
REAR PANEL ASSY
DISASSEMBLY
11. REAR PANEL ASSY
and "EXPLODED VIEW"
FCBS PCB
Ref. No. of EXPLODED VIEW : P 2-3
SPK PCB
Ref. No. of EXPLODED VIEW : P 3-3
SMPS ASSY
DISASSEMBLY
2. SMPS ASSY
and "EXPLODED VIEW"
SMPS600
Ref. No. of EXPLODED VIEW : MP 001
SMPS600
Ref. No. of EXPLODED VIEW : MP 002
RCA PCB
DISASSEMBLY
4. RCA PCB
and "EXPLODED VIEW"
RCA PCB
Ref. No. of EXPLODED VIEW : P 2-2
SPACER PCB
Ref. No. of EXPLODED VIEW : P 2-4
AUDIO IN PCB
DISASSEMBLY
1. AUDIO IN PCB
and "EXPLODED VIEW"
AUDIO IN PCB
Ref. No. of EXPLODED VIEW : P 2-1
FRONT PANEL ASSY
DISASSEMBLY
3. FRONT PANEL ASSY
and "EXPLODED VIEW"
UCOM PCB
Ref. No. of EXPLODED VIEW : P 1-3
LED R PCB
Ref. No. of EXPLODED VIEW : P 1-4
LED L PCB
Ref. No. of EXPLODED VIEW : P 1-5
VOLUME PCB
Ref. No. of EXPLODED VIEW : P 1-6
BACKLIGHT PCB
Ref. No. of EXPLODED VIEW : P 1-7
HP PCB
Ref. No. of EXPLODED VIEW : P 1-8
POWER SW PCB
Ref. No. of EXPLODED VIEW : P 1-9
REG PCB
Ref. No. of EXPLODED VIEW : P 3-4
SEL SW PCB
Ref. No. of EXPLODED VIEW : P 3-5
