Specifications
• RMS Power output
(20 Hz – 20 kHz simultaneous drive of both channels) : 45 W x 2 (8 Ω/ohms load)
60 W x 2 (4 Ω/ohms load)
• Total harmonic distortion
(20 Hz – 20 kHz simultaneous drive of both channels,
8 Ω/ohms load) : 0.08 %
• Output band width (8 Ω/ohms load, 0.06 %) : 10 Hz – 50 kHz
• Frequency response (CD, 1 W, 8 Ω/ohms load) : 10 Hz – 70 kHz +0 dB, –1 dB
• Dumping factor (8 Ω/ohms load, 40 Hz – 20 kHz) : 100
• Input sensitivity/Input impedance
PHONO (MM) :
CD, TUNER, NETWORK, RECORDER :
2.2 mV/47 kΩ/kohms
200 mV/20 kΩ/kohms
• Maximum allowable PHONO input level (1 kHz) MM : 100 mV
• RIAA deviation (20 Hz – 20 kHz) : ±1.0 dB
• S/N (IHF-A, 8 Ω/ohms load)
PHONO (MM) :
CD, TUNER, NETWORK, RECORDER :
83 dB (5 mV input, 1 W output)
102 dB (2 V input, Rated output)
• Tone control
Bass (50 Hz) :
Treble (15 kHz) :
±10 dB
±10 dB
• Digital input
Coaxial :
Optical :
0.5 Vp-p
–27 dBm or later
• Power requirement : AC 120 V, 60 Hz
• Power consumption (UL60065) : 155 W
• Power consumption in standby mode : 0.3 W
For the purpose of improvement, the specifications and design are subject to change without notice.
