Marantz PM6005 User Manual

5
Appendix
TipsSettingsPlaybackConnections
Contents
Front panel Rear panel IndexRemote
Inserting the batteries
q Remove the rear lid in the direction of
the arrow and remove it.
w Load the two batteries properly as
indicated by the q and w marks in the
battery compartment.
R03/AAA
batteries
e Put the rear cover back on.
NOTE
• When inserting the batteries, be sure to do so in the proper direction, following the
q and w marks in the battery compartment.
• To prevent damage or leakage of battery fluid:
• Do not use a new battery together with an old one.
• Do not use two dierent types of batteries.
• Remove the batteries from the remote control unit if it will not be in use for long
periods.
• If the battery fluid should leak, carefully wipe the fluid o the inside of the battery
compartment and insert new batteries.
Operating range of the remote control unit
Point the remote control unit at the remote sensor when operating it.
30°30°
Approx. 23 ft/7 m

Marantz PM6005 Specifications

General

Amplifier class	-
Frequency range	10 - 70000 Hz
Input sensitivity	200 mV
Audio output channels	2.0 channels
Peak power per channel	60 W
Signal-to-Noise Ratio (SNR)	102 dB
Total Harmonic Distortion (THD)	0.08 %
RMS power output per channel (8 Ohm)	45 W
AC (power) in	Yes
Audio (L/R) in	5
Audio (L/R) out	1
Speakers connectivity type	RCA
Purpose	Home
Product color	Black
Connectivity technology	Wired
AC input voltage	120 V
AC input frequency	60 Hz
Power consumption (standby)	0.3 W
Power consumption (typical)	155 W

Weight and Dimensions

Depth	370 mm
Width	440 mm
Height	105 mm
Weight	7600 g
