Marantz SR 8015 - Hdmi Block

AUDIO CHECK PATH
Analog audio BLOCK
Digital audio BLOCK
HDMI BLOCK
CHECK6
CHECK5
CHECK4
CHECK3
CHECK2
CHECK1
DIGITAL AUDIO
INTERFACE RECEIVER
NJU72750V & NJU72343V
5M570ZF256C5N
I2S
SELECTOR
I2S
AK4458 or PCM5102A
PLD
PCM9211PTR
DIR
AK5358BET or PCM1803A
ADC
INPUT
ANALOG 2CH
INPUT
NETWORK
INPUT
DIGITAL
INPUT
HDMI
INPUT
HDMI
FRONT
ETHERNET
USB
OPTICAL
COAXIAL
A/D_INPUT
D/A_OUTPUT
ADC
BLOCK
SPDIF
I2S/DSD
SPDIF(Legacy Audio)
I2S/HBR Audio(LPCM MULTI)
/Dolby TrueHD/DTS-HD MA/DSD
OUTPUT
HDMI
INPUT
HDMI
ADSP-21573KBCZ4 x2
VOLUME & INPUT SELECTOR
NETWORK BLOCK
Wifi
NETWORK
MODULE
Wifi/Bluetooth
HDMI Transceiver
MN864807
HDMI Trancseiver
MN864788
s
s
106
