1.4. Error display
See the table below for descriptions of the displayed errors and countermeasures for these.
If multiple errors occur, only one item is displayed.
The priority order is
w
,
e
,
r
,
t
,
y
,
q
.
Condition States Display TROUBLE SHOOTING
q
Firm Check
Error
The model name, brand name and region information written in the rmware are compared
to the region settings in the PCB. This error is displayed if the information does not match.
" ▲ " is not displayed if rmware information is correct.
FIRM ERROR
–
M:*************
–
Main FBL :**.**
–
DSP :**.**
–
A.PLD :********
–
V.PLD :********
–
GUI :********
• Check the resistor for setting the region[R6217, R6218,
R6219, DIGITAL PCB].
• Write the rmware for the correct region.
w
IP SCALER Er-
ror
An error occurs in Loop back Test of the DDR memory which is performed during the initial
setting of i/p Scaler(ADV8003).
IP SCALER ERR 01
• Check the circuits around the IP SCALER [U2800, DIGITAL
PCB] and DDR2 [U3000/U3001].
If there appear to be no problems, [U2800] or [U3000/U3001]
is faulty.
During the initial setting of i/p Scaler (ADV8003) , there is not the reply of the Loop back Test
result of the DDR memory .
IP SCALER ERR 02
e
GUI Serial
Flash Error
If the MCU version is not supported by the GUI Serial Flash (ADV8003),
" ▼ " is displayed as the rst character of the GUI rmware version.
If GUI Serial Flash is damaged, " ▲ " is displayed as the rst character.
GUI VER. ERROR
•
GUI :********
–
GUI :********
• Check the rmware version.
r
DIR Error
This error is displayed if there is no response from the DIR.
DIR ERROR 01
• Check the DIR [U7004, DIGITAL PCB] and surrounding cir-
cuits.
t
DSP
#
NG
(
#
: 1/2)
Boot error 1 (After reset the DSP, DSP_Flag0 port is "Low")
DSP# ERROR 01
• Check the DSP [U102, U252, DIGITAL PCB] and surrounding
circuits.
Boot error 2 (After reset the DSP, DSP initialization is not completed)
DSP# ERROR 02
(Unused)
DSP# ERROR 03
Command error 1 (After sending the command to the DSP, DSP_Flag0 port is "Low".)
DSP# ERROR 04
Command error 2 (After sending the command to the DSP, MCU received "COMMAND ER-
ROR".)
DSP# ERROR 05
Command error 3 (After sending the command to the DSP, MCU did not receive "COMMAND
SUCCESS".)
DSP# ERROR 06
IDL error 1 (Before receiving IDL, "COMMAND BYTE" is not cleared.)
DSP# ERROR 07
IDL error 2 (MCU received "IDL SERIOUS ERROR".)
DSP# ERROR 08
SPI communication error
DSP# ERROR 09
y
BACKUP Error
Error occurred in BACKUP. it is an error of the check sum.
BACKUP ERROR
151
