(3) Removethescrews.RemovethePUSHRIVET.Removetheconnector.
(4) Removethescrews.RemovetheSTYLEPIN.Removetheconnector.
x1
x1
L-AMP CONNECT
H2L
PURPLE
H1L
YELLOW
SBL
GRAY
SL
BROWN
FL
RED
C
BLUE
R-AMP CONNECT
FR
RED
SR
BROWN
SBR
GRAY
H1R
YELLOW
H2R
PURPLE
N5819 N5812N5822 N5831
PC SHEET
PUSH RIVET x2
x2
N9018 N9019
N6012
N9022 N9023
N6201
N3403
STYLE PIN x5
Proceeding : TOP COVER → RADIATOR ASSY or REAR ASSY → TRANS
(1) Removethescrews.RemovetheSTYLEPIN.Removetheconnector.
4. TRANS
x8
N6012
N6201
N6501
B1001
STYLE PIN x5
89
