60
109
P17/TIOCB2/
TCLKD
I/O,I/O,I/O I I M_RC_IN L H Multi RC5 IN Detect Signal
110
P16/TIOCA2/
~IRQ1
I/O,I/O,I INT INT WAKEUP - Standby Mode Release
111
P15/TIOCB1/
TCLKC
I/O,I/O,I/O T_IN I VSYNC - V-sync Det. & Change OSD
112
P14/TIOCA1/
~IRQ0
I/O,I/O,I INT I _P_DPWN L - Power Down Detect
113
P13/
TIOCD0/
TCLKB
I/O,I/O,I/O O O KILLIR H L Kill to IR Input Signal
114
P12/
TIOCC0/
TCLKA
I/O,I/O,I/O O I DC_OUT1 L H DC Triger1
115 P11/TIOCB0 I/O,I/O O I MV_MUTE BD3812F MultiVol
116 P10/TIOCA0 I/O,I/O T_IN I RC_IN - IR In for RC-5
117 Vss I YES I VSS - - GND
118 P2Vcc I YES I VCC - - +5V’
119 P37/TxD4 I/O,O SO O XM_TXD XM->
120 P36/RxD4 I/O,I SI I XM_RXD <-XM
121
P35/SCK1/
SCK4/SCL0/
~IRQ5
I/O,I/O,I/O,I/O,I INT I HDMI_INT TX or RX or SCDT
122
P34/RxD1/
SDA0
I/O,I,I/O I I HDMI_MUTE H L MUTE INPUT for HDMI
123
P33/TxD1/
SCL1
I/O,O,I/O SC I V_SCL - - Video Conv CLK
124
P32/SCK0/
SDA1/~IRQ4
I/O,I/O,I/O,I SIO I V_SDA - - Video Conv DATA
125 P31/RxD0 I/O,I SI I RXD
UART for RS232C, Flash WR
Pull UP (RESET : H)
126 P30/TxD0 I/O,O SC I TXD
UART for RS232C, Flash WR
Pull UP
127 P77/TxD3 I/O,O SO O OSDDATA - -
FrontFL,Video(OSD),Y/C&Sepa,
4094,SAA,AK
128 P76/RxD3 I/O,I I I PULL DOWN
129
P75/TMO3/
SCK3
I/O,I/O,I/O SC I OSDCLK - -
FrontFL,Video(OSD),Y/C&Sepa,
4094,SAA,AK
130
P74/TMO2/
~MRES
I/O,O O I _RSTFL L L Reset FL Driver
131 P73/TMO1 I/O,O I I _CEFL L L FL Driver Chip Select
132 P72/TMO0 I/O,O I I PULL DOWN
133
P71/TMRI23/
TMCI23
I/O,O,O I I PULL DOWN
134
P70/TMRI01/
TMCI01
I/O,O,O O I CLK_SW TC74VHC157 SEL
135 PG4 I/O O I _SCS L H DSP CHIP ENABLE
136 PG3 I/O O I _RSTDSP L L DSP
137 PG2 I/O O I _FCS L H DSP CHIP ENABLE
138 PG1/~IRQ7 I/O,I INT I IRQ7 - - RDS Clock
139 PG0/~IRQ6 I/O,I INT I IRQ6 - - XM_IRQ
140 PE0 I/O O I MONO H L Multi Mono(H)/Stereo(L)
141 PE1 I/O O I _CEEX L H P-Exp(Video)Sel A
142 PE2 I/O O I Y_OSD H L Y/C_OSD_IC_BYPASS
143 PE3 I/O O I CVBS_OSD H L CVBS_OSD_IC_BYPASS
144 PE4 I/O O I _CEOSD L H Video Circuit
IC11 : HD64F2505
pin
No
Port Name
Mode7
I/O use STBY Name
Port Setting
Note
Act. init
To Next Page
