SURROUND MODE
This unit is equipped with many surround modes. These are provided to reproduce a variety of surround
sound effects, according to the content of the source to be played.
The available surround modes may be restricted depending on the input signal and speaker setup.
THE RELATIONSHIP BETWEEN THE SELECTED SURROUND MODE AND THE INPUT SIGNAL
The surround mode is selected with the surround mode selector on the unit or the remote controller.
However, the sound you hear is subject to the relationship between the selected surround mode and the
input signal. That relationship is as follows:
OTHERS
Surround
Mode
Input Signal Decoding
Output Channel Front information display
L/R C
SL
SR
HL
HR
SBL
SBR
SubW
Signal format
indicators
Channel status
AUTO Dolby Surr.EX Dolby Digital EX
‡‡ ‡
–
‡‡
2
DIGITAL EX L, C, R, SL, SR, S, LFE
Dolby D (5.1ch) Dolby Digital 5.1
‡‡ ‡
––
‡
2
DIGITAL L, C, R, SL, SR, LFE
Dolby D (2ch) Dolby Digital 2.0
‡
–– – –
‡
2
DIGITAL L, R
Dolby D (2ch Surr) Pro Logic
II
x movie
‡‡ ‡
–
‡‡
2
DIGITAL L, R, S
Dolby Digital Plus (2ch) DolbyDigital +
‡
–– – –
‡
2
DIGITAL PLUS L, R
Dolby Digital Plus (5.1ch) DolbyDigital +
‡‡ ‡
––
‡
2
DIGITAL PLUS L, C, R, SL, SR, LFE
Dolby Digital Plus (6.1ch) DolbyDigital +
‡‡ ‡
–
‡‡
2
DIGITAL PLUS L, C, R, SL, SR, S, LFE (,ex1)
Dolby Digital Plus (7.1ch) DolbyDigital +
‡‡ ‡
–
‡‡
2
DIGITAL PLUS L, C, R, SL, SR, SBL, SBR, LFE
Dolby TrueHD (2ch) DolbyTrueHD
‡
–– – –
‡
2
TrueHD L, R
Dolby TrueHD (5.1ch) DolbyTrueHD
‡‡ ‡
––
‡
2
TrueHD L, C, R, SL, SR, LFE (,ex1,ex2)
Dolby TrueHD (6.1ch) DolbyTrueHD
‡‡ ‡
–
‡‡
2
TrueHD L, C, R, SL, SR, S, LFE (,ex1,ex2)
Dolby TrueHD (7.1ch) DolbyTrueHD
‡‡ ‡
–
‡‡
2
TrueHD L, C, R, SL, SR, SBL, SBR, LFE (,ex1,ex2)
Dolby TrueHD 192kHz (5.1ch) DolbyTrueHD
‡‡ ‡
––
‡
2
TrueHD L, C, R, SL, SR, LFE
DTS-ES DTS-ES
‡‡ ‡
–
‡‡
dts, ES L, C, R, SL, SR, S, LFE
DTS 96/24 DTS-96/24
‡‡ ‡
––
‡
dts 96/24 L, C, R, SL, SR, LFE
DTS (5.1ch) DTS 5.1
‡‡ ‡
––
‡
dts L, C, R, SL, SR, LFE
DTS-HD (2ch) DTS-HD
‡
–– – –
‡
dts-HD MSTR/HIRES L, R
DTS-HD (5.1ch) DTS-HD
‡‡ ‡
––
‡
dts-HD MSTR/HIRES L, C, R, SL, SR, LFE (,ex1,ex2)
DTS-HD (6.1ch) DTS-HD
‡‡ ‡
–
‡‡
dts-HD MSTR/HIRES L, C, R, SL, SR, S, LFE (,ex1,ex2)
DTS-HD (7.1ch) DTS-HD
‡‡ ‡
–
‡‡
dts-HD MSTR/HIRES L, C, R, SL, SR, SBL, SBR, LFE (,ex1,ex2)
DTS Express DTS EXPRESS
‡‡ ‡
––
‡
dts express L, C, R, SL, SR, LFE
Multi Ch-PCM Multi Ch-PCM
‡‡ ‡
––
‡
PCM L, C, R, SL, SR, LFE
Multi Ch-PCM 96kHz Multi Ch-PCM 96kHz
‡‡ ‡
––
‡
PCM L, C, R, SL, SR, LFE
Multi Ch-PCM 192kHz Multi Ch-PCM 192kHz
‡‡ ‡
––
‡
PCM L, C, R, SL, SR, LFE
SA-CD (5.1ch) SA-CD (5.1ch)
‡‡ ‡
––
‡
DSD L, C, R, SL, SR, LFE
SA-CD (2ch) SA-CD (Stereo)
‡
–– – –
‡
DSD L, R
PCM (Audio) PCM (Stereo)
‡
–– – –
‡
PCM L, R
PCM 96kHz PCM (Stereo 96kHz)
‡
–– – –
‡
PCM L, R
HDCD HDCD
‡
–– – –
‡
PCM, HDCD L, R
Analog Stereo
‡
–– – –
‡
ANALOG -
7.1ch input Multi Ch
‡‡ ‡
–
‡‡
ANALOG -
SOURCE
DIRECT
PURE DIRECT
Dolby Surr.EX Dolby Digital EX
‡‡ ‡
–
‡‡
2
DIGITAL EX L, C, R, SL, SR, S, LFE
Dolby D (5.1ch) Dolby Digital 5.1
‡‡ ‡
––
‡
2
DIGITAL L, C, R, SL, SR, LFE
Dolby D (2ch) Dolby Digital 2.0
‡
–––––
2
DIGITAL L, R
Dolby D (2ch Surr) Pro Logic
II
x movie
‡‡ ‡
–
‡‡
2
DIGITAL L, R, S
Dolby Digital Plus (2ch) DolbyDigital +
‡
–––––
2
DIGITAL PLUS L, R
Dolby Digital Plus (5.1ch) DolbyDigital +
‡‡ ‡
––
‡
2
DIGITAL PLUS L, C, R, SL, SR, LFE
Dolby Digital Plus (6.1ch) DolbyDigital +
‡‡ ‡
–
‡‡
2
DIGITAL PLUS L, C, R, SL, SR, S, LFE (,ex1)
Dolby Digital Plus (7.1ch) DolbyDigital +
‡‡ ‡
–
‡‡
2
DIGITAL PLUS L, C, R, SL, SR, SBL, SBR, LFE
Dolby TrueHD (2ch) DolbyTrueHD
‡
–––––
2
TrueHD L, R
Dolby TrueHD (5.1ch) DolbyTrueHD
‡‡ ‡
––
‡
2
TrueHD L, C, R, SL, SR, LFE (,ex1,ex2)
Dolby TrueHD (6.1ch) DolbyTrueHD
‡‡ ‡
–
‡‡
2
TrueHD L, C, R, SL, SR, S, LFE (,ex1,ex2)
Dolby TrueHD (7.1ch) DolbyTrueHD
‡‡ ‡
–
‡‡
2
TrueHD L, C, R, SL, SR, SBL, SBR, LFE (,ex1,ex2)
Dolby TrueHD 192kHz (5.1ch) DolbyTrueHD
‡‡ ‡
––
‡
2
TrueHD L, C, R, SL, SR, LFE
DTS-ES DTS-ES
‡‡ ‡
–
‡‡
dts, ES L, C, R, SL, SR, S, LFE
DTS 96/24 DTS-96/24
‡‡ ‡
––
‡
dts 96/24 L, C, R, SL, SR, LFE
DTS (5.1ch) DTS 5.1
‡‡ ‡
––
‡
dts L, C, R, SL, SR, LFE
DTS-HD (2ch) DTS-HD
‡
––––– dts-HD MSTR/HIRES L, R
DTS-HD (5.1ch) DTS-HD
‡‡ ‡
––
‡
dts-HD MSTR/HIRES L, C, R, SL, SR, LFE (,ex1,ex2)
DTS-HD (6.1ch) DTS-HD
‡‡ ‡
–
‡‡
dts-HD MSTR/HIRES L, C, R, SL, SR, S, LFE (,ex1,ex2)
DTS-HD (7.1ch) DTS-HD
‡‡ ‡
–
‡‡
dts-HD MSTR/HIRES L, C, R, SL, SR, SBL, SBR, LFE (,ex1,ex2)
DTS Express DTS EXPRESS
‡‡ ‡
––
‡
dts express L, C, R, SL, SR, LFE
Multi Ch-PCM Multi Ch-PCM
‡‡ ‡
––
‡
PCM L, C, R, SL, SR, LFE
Multi Ch-PCM 96kHz Multi Ch-PCM 96kHz
‡‡ ‡
––
‡
PCM L, C, R, SL, SR, LFE
Multi Ch-PCM 192kHz Multi Ch-PCM 192kHz
‡‡ ‡
––
‡
PCM L, C, R, SL, SR, LFE
SA-CD (5.1ch) SA-CD (5.1ch)
‡‡ ‡
––
‡
DSD L, C, R, SL, SR, LFE
Surround
Mode
Input Signal Decoding
Output Channel Front information display
L/R C
SL
SR
HL
HR
SBL
SBR
SubW
Signal format
indicators
Channel status
SOURCE
DIRECT
PURE DIRECT
SA-CD (2ch) SA-CD (Stereo)
‡
–– – –
‡
DSD L, R
PCM (Audio) PCM (Stereo)
‡
––––– PCM L, R
PCM 96kHz PCM (Stereo 96kHz)
‡
––––– PCM L, R
HDCD HDCD
‡
––––– PCM, HDCD L, R
Analog Stereo
‡
––––– ANALOG -
7.1ch input Multi Ch
‡‡ ‡
–
‡‡
ANALOG -
EX/ES Dolby Surr.EX Dolby Digital EX
‡‡ ‡
–
‡‡
2
DIGITAL EX L, C, R, SL, SR, S, LFE
Dolby D (5.1ch) Dolby Digital EX
‡‡ ‡
–
‡‡
2
DIGITAL L, C, R, SL, SR, LFE
Dolby Digital Plus (5.1ch) DolbyDigital + +EX
‡‡ ‡
–
‡‡
2
DIGITAL PLUS L, C, R, SL, SR, LFE
Dolby TrueHD (5.1ch) DolbyTrueHD +EX
‡‡ ‡
–
‡‡
2
TrueHD L, C, R, SL, SR, LFE (,ex1,ex2)
DTS-ES DTS-ES
‡‡ ‡
–
‡‡
dts, ES L, C, R, SL, SR, S, LFE
DTS (5.1ch) DTS-ES
‡‡ ‡
–
‡‡
dts L, C, R, SL, SR, LFE
DTS-HD (5.1) DTS-HD + NEO6
‡‡ ‡
–
‡‡
dts-HD MSTR/HIRES L, C, R, SL, SR, LFE (,ex1,ex2)
Multi-PCM
Multi Ch-PCM +
Dolby Digital EX
‡‡ ‡
–
‡‡
PCM L, C, R, SL, SR, SW
SA-CD (5.1ch)
SA-CD (5.1ch) +
Dolby Digital EX
‡‡ ‡
–
‡‡
DSD L, C, R, SL, SR, SW
DOLBY PL
II
z Dolby Surr.EX Dolby Digital 5.1 + PL
II
z
‡‡ ‡ ‡
–
‡
2
DIGITAL EX L, C, R, SL, SR, S, LFE
Dolby D (5.1ch)
Dolby Digital 5.1+ +
PL
II
z
‡‡ ‡ ‡
–
‡
2
DIGITAL L, C, R, SL, SR, LFE
Dolby D (2ch) PL
II
z
‡‡ ‡ ‡
–
‡
2
DIGITAL L, R
Dolby D (2ch Surr) PL
II
z
‡‡ ‡ ‡
–
‡
2
DIGITAL L, R, S
Dolby Digital Plus (2ch) PL
II
z
‡‡ ‡ ‡
–
‡
2
DIGITAL PLUS L, R
Dolby Digital Plus (5.1ch)
DolbyDigital Plus + PL
II
z
‡‡ ‡ ‡
–
‡
2
DIGITAL PLUS L, C, R, SL, SR, LFE
Dolby Digital Plus (6.1ch)
DolbyDigital Plus + PL
II
z
‡‡ ‡ ‡
–
‡
2
DIGITAL PLUS L, C, R, SL, SR, S,LFE
Dolby Digital Plus (7.1ch)
DolbyDigital Plus + PL
II
z
‡‡ ‡ ‡
–
‡
2
DIGITAL PLUS L, C, R, SL, SR, SBL, SBR, LFE
Dolby TrueHD (2ch) PL
II
z
‡‡ ‡ ‡
–
‡
2
TrueHD L, R
Dolby TrueHD (5.1ch) DolbyTrueHD + PL
II
z
‡‡ ‡ ‡
–
‡
2
TrueHD L, C, R, SL, SR, LFE (,ex1,ex2)
Dolby TrueHD (6.1ch) DolbyTrueHD + PL
II
z
‡‡ ‡
––
‡
2
TrueHD L, C, R, SL, SR, S, LFE (,ex1,ex2)
Dolby TrueHD (7.1ch) DolbyTrueHD + PL
II
z
‡‡ ‡ ‡
–
‡
2
TrueHD
L, C, R, SL, SR, SBL, SBR, LFE (,ex1,ex2)
DTS-HD (2ch) PL
II
z
‡‡ ‡ ‡
–
‡
2
TrueHD L, R
Multi Ch-PCM Multi Ch-PCM + PL
II
z
‡‡ ‡ ‡
–
‡
PCM L, C, R, SL, SR, LFE
SA-CD (5.1ch) SA-CD (5.1ch) + PL
II
z
‡‡ ‡ ‡
–
‡
DSD L, C, R, SL, SR, LFE
SA-CD (2ch) PL
II
z
‡‡ ‡ ‡
–
‡
DSD L, R
PCM (Audio) PL
II
z
‡‡ ‡ ‡
–
‡
PCM L, R
HDCD PL
II
z
‡‡ ‡ ‡
–
‡
PCM, HDCD L, R
Analog PL
II
z
‡‡ ‡ ‡
–
‡
ANALOG –
DOLBY
(PL
II
x movie)
(PL
II
x music)
(PL
II
x game)
Dolby Surr.EX Dolby Digital EX
‡‡ ‡
––
‡
2
DIGITAL EX L, C, R, SL, SR, S, LFE
Dolby D (5.1ch) Dolby Digital 5.1
‡‡ ‡
––
‡
2
DIGITAL L, C, R, SL, SR, LFE
Dolby D (5.1ch)
Dolby Digital 5.1 + PL
II
x
‡‡ ‡
–
‡‡
2
DIGITAL L, C, R, SL, SR, LFE
Dolby D (2ch) Pro Logic
II
x
‡‡ ‡
–
‡‡
2
DIGITAL L, R
Dolby D (2ch Surr) Pro Logic
II
x
‡‡ ‡
–
‡‡
2
DIGITAL L, R, S
Dolby Digital Plus (2ch) Pro Logic
II
x
‡‡ ‡
–
‡‡
2
DIGITAL PLUS L, R
Dolby Digital Plus (5.1ch) DolbyDigital +
‡‡ ‡
––
‡
2
DIGITAL PLUS L, C, R, SL, SR, LFE
Dolby Digital Plus (5.1ch)
Dolby Digital Plus + PL
II
x
‡‡ ‡
–
‡‡
2
DIGITAL PLUS L, C, R, SL, SR, LFE
Dolby TrueHD (2ch) Pro Logic
II
x
‡‡ ‡
–
‡‡
2
TrueHD L, R
Dolby TrueHD (5.1ch) DolbyTrueHD + PL
II
x
‡‡ ‡
–
‡‡
2
TrueHD L, C, R, SL, SR, LFE (,ex1,ex2)
Dolby TrueHD (5.1ch) DolbyTrueHD
‡‡ ‡
––
‡
2
TrueHD L, C, R, SL, SR, LFE (,ex1,ex2)
DTS-HD (2ch) DTS-HD
‡‡ ‡
–
‡‡
2
TrueHD L, R
Multi Ch-PCM Multi Ch-PCM + PL
II
x
‡‡ ‡
–
‡‡
PCM L, C, R, SL, SR, LFE
SA-CD (5.1ch) SA-CD (5.1ch) + PL
II
x
‡‡ ‡
–
‡‡
DSD L, C, R, SL, SR, LFE
SA-CD (2ch) Pro Logic
II
x
‡‡ ‡
–
‡‡
DSD L, R
PCM (Audio) Pro Logic
II
x
‡‡ ‡
–
‡‡
PCM L, R
HDCD Pro Logic
II
x
‡‡ ‡
–
‡‡
PCM, HDCD L, R
Analog Pro Logic
II
x
‡‡ ‡
–
‡‡
ANALOG -
DTS
(Neo:6
Cinema)
(Neo:6 Music)
DTS-ES DTS 5.1
‡‡ ‡
––
‡
dts, ES L, C, R, SL, SR, S, LFE
DTS 96/24 DTS-96/24
‡‡ ‡
––
‡
dts 96/24 L, C, R, SL, SR, LFE
DTS (5.1ch) DTS 5.1
‡‡ ‡
––
‡
dts L, C, R, SL, SR, LFE
DTS-HD (2ch) Neo:6
‡‡ ‡
–
‡‡
dts-HD MSTR/HIRES L, R
DTS-HD (5.1ch) DTS-HD
‡‡ ‡
––
‡
dts-HD MSTR/HIRES L, C, R, SL, SR, LFE (,ex1,ex2)
DTS-HD (6.1ch) DTS-HD
‡‡ ‡
–
‡‡
dts-HD MSTR/HIRES L, C, R, SL, SR, S, LFE (,ex1,ex2)
DTS-HD (7.1ch) DTS-HD
‡‡ ‡
–
‡‡
dts-HD MSTR/HIRES
L, C, R, SL, SR, SBL, SBR, LFE
(,ex1,ex2)
Dolby D (2ch) Neo:6
‡‡ ‡
–
‡‡
2
DIGITAL L, R
Dolby D (2ch Surr) Neo:6
‡‡ ‡
–
‡‡
2
DIGITAL L, R, S
Dolby Digital Plus (2ch) Neo:6
‡‡ ‡
–
‡‡
2
DIGITAL PLUS L, R
Dolby TrueHD (2ch) Neo:6
‡‡ ‡
–
‡‡
2
TrueHD L, R
SA-CD (2ch) Neo:6
‡‡ ‡
–
‡‡
DSD L, R
PCM (Audio) Neo:6
‡‡ ‡
–
‡‡
PCM L, R
HDCD Neo:6
‡‡ ‡
–
‡‡
PCM, HDCD L, R
Analog Neo:6
‡‡ ‡
–
‡‡
ANALOG -

Marantz SR5004 Specifications

General

Channels	7.1
HDMI Outputs	1
Video Upscaling	Yes, up to 1080p
Response Bandwidth	10 Hz - 100 kHz
Signal-To-Noise Ratio	100 dB
THD	0.08%
Input Impedance	47 kOhm
Input Sensitivity	200 mV
HDMI Switching	Yes
3D Technology	Yes
Frequency Response	10 Hz - 100 kHz
USB Port	No
Dolby Technologies	Dolby Digital Plus, Dolby TrueHD
DTS Technologies	DTS-HD Master Audio, DTS Neo:6
Amplifier Output Details	90 watts per channel (8 ohms, 20 Hz - 20 kHz, 0.08% THD)
Tuning Range	AM/FM
Video Upconversion	Yes
